Xindun LS series split-phase inverter 12V/24V/48V, supports dual voltage output. That is, the same inverter can output 110VAC and 220VAC, or output 120VAC and 240VAC. Ideal for customers in the Americas. On this page, we show 1000w-6000w split phase inverters. If you are interested in high-power split phase inverters, please click the link to view.
One inverter has two commonly used output voltage, customers do not need to prepare multiple inverters, and it is more convenient to use. The split phase inverter adopts toroidal transformer, which has low loss and less noise. In terms of battery type, it is compatible with the most popular lead-acid batteries and lithium batteries in the market, and can charge the batteries, too.
Note that the battery voltage 12V/24V/48V cannot be self-adapted, please clarify the battery voltage before placing an order.
Note that the battery voltage 12V/24V/48V cannot be self-adapted, please clarify the battery voltage before placing an order.
| Split Phase Inverter Specification | ||||||||
| Model LS | 10212/24/48 (102) | 15212/24/48 (152) | 20212/24/48 (202) | 30224/48 (302) | 40224/48 (402) | 50248 (502) | 60248 (602) | |
| Rated Power | 1000W | 1500W | 2000W | 3000W | 4000W | 5000W | 6000W | |
| Peak Power(20ms) | 3000VA | 4500VA | 6000VA | 9000VA | 12000VA | 15000VA | 18000VA | |
| Start Motor | 1HP | 1.5HP | 2HP | 3HP | 3HP | 4HP | 4HP | |
| Battery Voltage | 12/24/48VDC | 24/48VDC | 24/48VDC | 48VDC | ||||
| Size(L*W*Hmm) | 500*300*140 | 530*335*150 | ||||||
| Packing Size(L*W*Hmm) | 565*395*225 | 605*430*235 | ||||||
| N.W.(kg) | 12 | 13.5 | 18 | 20 | 22 | 24 | 26 | |
| G.W.(kg)(Carton Packing) | 13.5 | 15 | 19.5 | 21.5 | 24 | 26 | 28 | |
| Installation Method | Wall-Mounted | |||||||
| Input | DC Input Voltage Range | 10.5-15VDC(Single battery voltage) | ||||||
| AC Input Voltage Range | 85VAC~138VAC(110VAC) / 95VAC~148VAC(120VAC) / 170VAC~275VAC(220VAC) / 190VAC~295VAC(240VAC) | |||||||
| AC Input Frequency Range | 45Hz~55Hz(50Hz) / 55Hz~65Hz(60Hz) | |||||||
| Max AC charging current | 0~30A(Depends on model) | |||||||
| AC charging method | Three-stage (constant current, constant voltage, floating charge) | |||||||
| Output | Efficiency(Battery Mode) | ≥85% | ||||||
| Output Voltage(Battery Mode) | L1-N/L2-N: 110VAC+2%; L1-L2: 220VAC+2% L1-N/L2-N: 120VAC+2%; L1-L2: 240VAC+2% | |||||||
| Output Frequency(Battery Mode) | 50/60Hz±1% | |||||||
| Output Wave(Battery Mode) | Pure Sine Wave | |||||||
| Efficiency(AC Mode) | >99% | |||||||
| Output Voltage(AC Mode) | L1-N/L2-N: 110VAC+2%; L1-L2: 220VAC+2% L1-N/L2-N: 120VAC+2%; L1-L2: 240VAC+2% | |||||||
| Output Frequency(AC Mode) | Follow input | |||||||
| Output waveform distortion (Battery Mode) | ≤3%(Linear load) | |||||||
| No load loss(Battery Mode) | ≤0.8% rated power | |||||||
| No load loss(AC Mode) | ≤2% rated power( charger does not work in AC mode) | |||||||
| No load loss (Energy saving Mode) | ≤10W | |||||||
| Battery Type | VRLA Battery | Charge Voltage :14.2V; Float Voltage:13.8V(Single battery voltage) | ||||||
| Customize battery | Charging and discharging parameters of different types of batteries
can be customized according to user requirements (charging and discharging parameters of different types of batteries can be set through the operation panel) | |||||||
| Protection | Battery undervoltage alarm | Factory default: 11V(Single battery voltage) | ||||||
| Battery undervoltage protection | Factory default: 10.5V(Single battery voltage) | |||||||
| Battery overvoltage alarm | Factory default: 15V(Single battery voltage) | |||||||
| Battery overvoltage protection | Factory default: 17V(Single battery voltage) | |||||||
| Battery overvoltage recovery voltage | Factory default: 14.5V(Single battery voltage) | |||||||
| Overload power protection | Automatic protection (battery mode), circuit breaker or insurance (AC mode) | |||||||
| Inverter output short circuit protection | Automatic protection (battery mode), circuit breaker or insurance (AC mode) | |||||||
| Temperature protection | >90°C(Shut down output) | |||||||
| Note: All specifications are subject to charge without prior notice | ||||||||
Xindun LS series split phase inverter adopts wall-mounted installation, which is the style preferred by 80% of buyers in the market. The following is the feedback map left by Xindun customers after installing and using the split phase inverter for more than half a year
Xindun was established in 2006 and is headquartered in China. We have overseas warehouses in Nigeria, Senegal, Kenya, Tanzania, Pakistan, Indonesia, and the Philippines. Over the years, we only provide high-quality split phase inverters. Split phase inverters have a large inventory and a variety of options.
Different from many trading companies, Xindun has positioned itself as a manufacturing enterprise since its establishment. For more than ten years, we have provided inverter OEM production and processing customization to countless brand owners. We have a high-quality R&D team, serious and responsible quality inspection department, more than 100 professionally trained technicians. Xindun's annual production capacity is 64000 sets of inverters. If you are choosing a split phase inverter manufacturer, then you can choose Xindun who has rich experience, contact us immediately, and give you some selection suggestions.
The production process of the split phase inverter is as follows: Material testing - Inserting - soldering - Assemble - 1st testing - Aging test - 2nd testing - Packaging - Delivery. In any link of production, our sales will report the progress to you, and we also welcome you to come to our factory to check the quality.
Xindun has been through wind and rain for decades, and has accumulated over 10,000 customers. Some inverters have been used for 8 years, and the quality is still good. "The quality of Xindun's inverter is the best among the five suppliers I have selected." "Xindun's service is very good, and the problem-solving efficiency is too high." "There are many styles of Xindun's inverters, and I can always choose the right one from their new products, and get good reviews from my clients"
|
|
